ROD 450 150 02S09-04 K 1.00 02 01J03B 64 28 .. .. RAP ~11µApp 07 01
Incremental rotary encoder with integral bearing for separate shaft coupling
Line count: 150
Output signal: ~11µApp
Cutoff frequency (-3dB): 180.00 kHz
Power supply: 5 V (+-10 %)
Flange version: Clamping flange 36 mm, bolt circle Ø 48 mm, 3 x M3
Shaft: Solid shaft, diameter 10 mm, length 20 mm
Degree of protection: IP64 (EN60529)
Operating temperature: -40/+100 °C
Electrical connection: Connector M23, male, 9-pin
Pin configuration: D295051
Connecting direction: Cable outlet for axial and radial use
Cable length: 1.00 m
Special characteristics, rotational encoders: none
Payment options
Manufacturer
ROD 450 150 02S09-04 K 1.00 02 01J03B 64 28 .. .. RAP ~11µApp 07 01
Incremental rotary encoder with integral bearing for separate shaft coupling
Line count: 150
Output signal: ~11µApp
Cutoff frequency (-3dB): 180.00 kHz
Power supply: 5 V (+-10 %)
Flange version: Clamping flange 36 mm, bolt circle Ø 48 mm, 3 x M3
Shaft: Solid shaft, diameter 10 mm, length 20 mm
Degree of protection: IP64 (EN60529)
Operating temperature: -40/+100 °C
Electrical connection: Connector M23, male, 9-pin
Pin configuration: D295051
Connecting direction: Cable outlet for axial and radial use
Cable length: 1.00 m
Special characteristics, rotational encoders: none
| Weight | 456 g |
|---|---|
| Interface | 11 µApp |
| Cable length | |
| Connector type | |
| Flange | |
| Shaft | |
| Line count | 150 |
