36.122,00 DKK 45.995,00 DKKPrisinterval: 36.122,00 DKK til 45.995,00 DKK ex. vat.
5.855,00 DKK ex. vat.
Select variation
Delivery
Delivery is calculated at checkout
ROQ 425 512 03S17-58 R 10.00 03 01J03C dC 01 .. .. D EnDat01 05
Absolute rotary encoder (multiturn) with integral
bearing for separate shaft coupling
Data interface: EnDat01 Synchronous serialEnDat 2.1 with incrementalsignals, command set EnDat2.1
Positions per revolution: 8192
Differentiable
revolutions: 4096
Output code: Dual
Line count: 512
Output signal: ~1Vpp
Cutoff frequency (-3dB):130.00 kHz
Power supply: 5 V (+-5 %)
Flange version: Clamping flange 36 mm, bolt circle Ø 48 mm, 3 x M4
Shaft: Solid shaft, diameter 10 mm, length 20 mm
Degree of protection: II 2 G Ex d IIC 120°C / II 2 D Ex tD A21 T120°C
Operating temperature: -10/+100 °C
Electrical connection: Coupling, male 17-pin
Pin configuration: D288678
Connecting direction: radial
Cable length: 10.00 m
Special characteristics, rotational encoders: none
Included part: Protective cap [377109-01]
Payment options
Manufacturer
ROQ 425 512 03S17-58 R 10.00 03 01J03C dC 01 .. .. D EnDat01 05
Absolute rotary encoder (multiturn) with integral
bearing for separate shaft coupling
Data interface: EnDat01 Synchronous serialEnDat 2.1 with incrementalsignals, command set EnDat2.1
Positions per revolution: 8192
Differentiable
revolutions: 4096
Output code: Dual
Line count: 512
Output signal: ~1Vpp
Cutoff frequency (-3dB):130.00 kHz
Power supply: 5 V (+-5 %)
Flange version: Clamping flange 36 mm, bolt circle Ø 48 mm, 3 x M4
Shaft: Solid shaft, diameter 10 mm, length 20 mm
Degree of protection: II 2 G Ex d IIC 120°C / II 2 D Ex tD A21 T120°C
Operating temperature: -10/+100 °C
Electrical connection: Coupling, male 17-pin
Pin configuration: D288678
Connecting direction: radial
Cable length: 10.00 m
Special characteristics, rotational encoders: none
Included part: Protective cap [377109-01]
| Interface | 1 Vpp |
|---|---|
| Voltage | |
| Connector type | |
| Line count | 512 |
| Cable length | |
| Flange |
