36.122,00 DKK 45.995,00 DKKPrisinterval: 36.122,00 DKK til 45.995,00 DKK ex. vat.
Select variation
Delivery
Delivery is calculated at checkout
ROQ 437 2048 1SS08-C4 K 1.00 01 73A01C 64 01 .. .. D EnDat22 34 01Absolute rotary encoder (multiturn) with integral
bearing for separate shaft coupling
Differentiable
revolutions: 4096
Positions per revolution: 33554432
Data interface: EnDat22 Synchronous serial
EnDat 2.2 without incremental signals
Output code: Dual
Line count: 2048
Power supply: 3.6 V ... 5.25 V
Flange version: Synchro flange Ø 58 mm, centering collar 50 mm,
bolt circle Ø 42 mm, 3 x M4
Shaft: Solid shaft, diameter 6 mm, length 9.5 mm
Degree of protection: IP 64 (EN 60529)
Operating temperature: -40/+100 °C
Electrical connection: Coupling M12, male, 8-pin
Pin configuration: D532351
Connecting direction: Cable outlet for axial andradial use
Cable length: 1.00 m
Compatible with:
Payment options
Manufacturer
ROQ 437 2048 1SS08-C4 K 1.00 01 73A01C 64 01 .. .. D EnDat22 34 01Absolute rotary encoder (multiturn) with integral
bearing for separate shaft coupling
Differentiable
revolutions: 4096
Positions per revolution: 33554432
Data interface: EnDat22 Synchronous serial
EnDat 2.2 without incremental signals
Output code: Dual
Line count: 2048
Power supply: 3.6 V ... 5.25 V
Flange version: Synchro flange Ø 58 mm, centering collar 50 mm,
bolt circle Ø 42 mm, 3 x M4
Shaft: Solid shaft, diameter 6 mm, length 9.5 mm
Degree of protection: IP 64 (EN 60529)
Operating temperature: -40/+100 °C
Electrical connection: Coupling M12, male, 8-pin
Pin configuration: D532351
Connecting direction: Cable outlet for axial andradial use
Cable length: 1.00 m
Compatible with:
| Weight | 430 g |
|---|---|
| Interface | HEIDENHAIN EnDat |
| Line count | 2048 |
| Cable length | |
| Connector type | |
| Flange | |
| Shaft |
