MT 12W 02S09 04 ~11µApp 01 .. 1.50 01 5.5 mm 64 AF 10.000 GF 01 1.0
Incremental length gauge HEIDENHAIN-METRO
Plunger actuation: Extended by spring force
Measuring length: 12 mm
Type of guide: sliding glide
Reference mark position:5.5 mm
Accuracy grade: 1.0 µm
Electrical connection: Connector M23, male, 9-pin
Pin configuration: D295051
Cable type: PUR Ø 4.5 mm
Cable length: 1.50 m
Output signal: sinusoidal current signals (11 µApp)
Signal period: 10.000 µm
Power supply: 5V+-5%
Degree of protection: IP64 (EN60529)
Operating temperature: +10/+40 °C
Betalningsalternativ
Producent
MT 12W 02S09 04 ~11µApp 01 .. 1.50 01 5.5 mm 64 AF 10.000 GF 01 1.0
Incremental length gauge HEIDENHAIN-METRO
Plunger actuation: Extended by spring force
Measuring length: 12 mm
Type of guide: sliding glide
Reference mark position:5.5 mm
Accuracy grade: 1.0 µm
Electrical connection: Connector M23, male, 9-pin
Pin configuration: D295051
Cable type: PUR Ø 4.5 mm
Cable length: 1.50 m
Output signal: sinusoidal current signals (11 µApp)
Signal period: 10.000 µm
Power supply: 5V+-5%
Degree of protection: IP64 (EN60529)
Operating temperature: +10/+40 °C
| Vikt | 1843 g |
|---|---|
| Interface | 11 µAss |
| Spänning | |
| Diameter | 4,5mm |
| Stik typ | |
| IP Klassificering | |
| Mätning av längd |
Teknisk information
Spare parts kit filter PNE 051/ 054/FS62
Kompatibel med:
2.499,00 DKK exkl. moms.
M4 silver steel crash protection device, L 16 mm - Break Shaft
150,00 DKK exkl. moms.
TS 750 .. 7DL02 QE 0.00 .. T434 .. .. 0069 Workpiece touch probe Repeatability: 0.25 µm Output signal: Electrical connection: PCBA contact strip, female, 2-pin Cable type: w/o cable Stylus geometry: T434 L=40 mm, ball Ø 4 mm, shaft Ø 3 mm, without rated break point Axial deflection force: 8.0 N Housing material: Steel, stainless (1.4104)
Kompatibel med:
26.600,00 DKK exkl. moms.
RMP600 Q probe (radio/radio) The RMP600 Q is a compact, high-accuracy touch probe with radio signal transmission. Excelling in the measurement of complex 3D shapes and contours, the RMP600 Q with RENGAGE technology is ideally suited to 5-axis machining applications.
49.995,00 DKK exkl. moms.
