HEIDENHAIN UR Forsyningsmodul (362593-02)

Modelnummer: 362593-02

Vælg variant

Levering

Levering bliver beregnet ved kassen

Beskrivelse

UR 230 22 40kW<0.2s
Compact Inverter regenerative
For 2-axes + spindle or 3-axes
Rated current 5 kHz: 2 x 7.5A-axes and 35A-spindle or 25A-axis
Max. current at 5 kHz: 2x 15A and 50A
Rated power: 22 kW
Power S6-40%: 30 kW
Peak power: 40kW<0.2s
DC-link voltage: 650 V
Low-voltage power supply
unit: 200 W
Type of heat removal: internal
Connection for holding
brakes: with connection
Module width: 250.00 mm
Ribbon cables and cover for ribbon cables are included in delivery

Betalingsmuligheder

Produktbeskrivelse

Producent

HEIDENHAIN

Beskrivelse

Produktdetaljer

Yderligere information

Vægt	25680 g
